All sizes of HDD rig drilling rods and pipes for all brand of horizontal directional drilling machine such as XCMG,Vermeer,Gudeng ects

Forged drill pipe

Size(mm) φ60*7.1*3000

Steel stage S135

Style Intergral

Thread type ZX60

Pipe outer diameter(inch/mm) 2.375/60

Wall thickness(inch/mm) 0.279/7.1

Connection outer diameter(inch/mm) 2.68/68

Rods effective length(ft/mm) 9.844/3000

Weight(kg) 32

Torque(N.m) 6500

Minimum radius of curvature(M) 33

Angle bending length(M) 52

Max bending angle(degree) 5.2

Max tile angle(%) 9

============================================================

Forged drill pipe

Size(mm)  φ73*8.1*3000

Steel stage S135

Style Intergral

Thread type  NC23

Pipe outer diameter(inch/mm)    8.875/73

Wall thickness(inch/mm)  0.315/8

Connection outer diameter(inch/mm)  3.17/82.5

Rods effective length(ft/mm)  9.844/3000

Weight(kg) 46

Torque(N.m)  13000

Minimum radius of curvature(M) 45

Angle bending length(M)   71

Max bending angle(degree)  3.8

Max tile angle(%)  6

========================================================

Forged drill pipe

Size(mm) φ73*10*3000

Steel stage S135

Style Intergral

Thread type NC26

Pipe outer diameter(inch/mm) 2.875/73

Wall thickness(inch/mm)  0.355/9

Connection outer diameter(inch/mm) 3.45/88

Rods effective length(ft/mm) 9.844/3000

Weight(kg)  56

Torque(N.m)  16000

Minimum radius of curvature(M)  62

Angle bending length(M)  97

Max bending angle(degree)  2.8

Max tile angle(%)  5

===========================================================
