XCMG XZ120E HDD Horizontal Directional Drill Trenchless Drilling Rig
Product Model：XZ120E Horizontal Directional Drill (HDD)
XCMG XZ120E HDD Drilling Rig structure compact, high performance, full-featured, hydraulic pilot control, sliding rack and pinion, the main performance parameters and control technology has reached the international advanced level. Hydraulic systems, power systems, running system, and the main components are made of domestic first-class brand products, good performance, good reliability

1.Features Introduction

1.Hydraulic pilot control, with comfortable handling and flexible regulation, first-class brand of hydraulic components to ensure the reliability of the whole hydraulic system
2.Rack and pinion sliding, to ensure the stability of the carriage and the reliability of drive
operational. Carriage floating, patented technology can greatly protect the drill pipe thread, increase the service life of the drill pipe.
3.High-speed sliding systems, variable motor to achieve high and low carriage sliding
change, increasing the ability to adapt the drilling rig working conditions, improve the
efficiency of the drilling rig construction.
4.Stable chassis support, using the classic H-beam structure, high quality rubber track,
provide a strong guarantee for the stability of the whole construction.
5.Machine with small inclination angle and low output shaft of carriage meet with
construction requirements ofsmall angle and short distance.

2.Technology Introduction

1.Hydraulic System

Using a hydraulic pilot control, hydraulic components are domestic first-class brand. Most important parts of hydraulic system are made of leading domestic and foreign products, good performance, good reliability.
Hydraulic system pressure 21MPa；
Fuel tank volume 140L；

2.Engine System

Dongfeng Cummins turbocharged engine is selected, with strong power and efficient construction.

3.Chassis

XZ120E HDD use classic H-beam structure, high quality rubber track, site adaptability, high
reliability, walking gear, stable performance, walking speed can reach 2km / h.

4.Carriage

The drilling rig completed by rack and pinion sliding action, carriage floating device can
effectively protect the drill thread, variable-speed motor to achieve sliding.

5.Mud Systerm

100L mud pump system according to the construction, to provide powerful construction, large flow, ensure the smooth construction.
Max. Mud pump flow 100L/min
Max. Mud pump pressure 40bar

6.Console

Collaboration with professional bodies, Cab, console ergonomics analysis and research,
fully considered during the operation operator comfort and instrument layout is reasonable.

7.Pipe Loader(Optional)

Machine can option automatic full-automatic pipe loader, to achieve handling drill
automation. Optional Full-automatic pipeloader, Drilling box can accommodate 48 piece of Φ52×1800 welded drill pipes, this system can add pipe capacity for long distance
construction Efficient automation construction, reduce construction costs and labor
intensity.
Note：This Full-automatic pipeloader use Φ52 welded drill pipes！

8.Anchor(Optional)

Main machine with normal anchor, also can option automatic anchor help push and
drill, highly automated and great power, reduce labor intensity.

9.Drill and Drilling Tools(Optional)

Other accessories of XZ120E horizontal directional drill rig are configured as follows:

3.Main Technical Parameters

4.Main Part Configuration

5.Transport Program

The machine transportation dimension 4500×1680×2170mm
Shiping weight(free of drill and drilling tools) 4.5t

6.Accompanied Attached Documents

XZ120E HDD machine start when accompanied by the packing list, include the following technical documents:
Product Certificate
Instruction Manual
Operation and Maintenance Manual of Engine
Quality Assurance Manual of Engine
Mud Pump Instruction Manual
Packing List (including accompanied spare details, accompanied tools list)
